Home /Products/WiFi LED Driver/RF frequency: 2.4GHz (support multiple drivers wireless-synchro-work) 2.4g led driver 15w rf led controller 30-45vdc 350ma 2.4g wireless TDC led driver

RF frequency: 2.4GHz (support multiple drivers wireless-synchro-work) 2.4g led driver 15w rf led controller 30-45vdc 350ma 2.4g wireless TDC led driver

1 Piece
MOQ
$3.00(1 - 49 Pieces) $2.50(50 - 499 Pieces) $2.00(>=500 Pieces)
Price
RF frequency: 2.4GHz (support multiple drivers wireless-synchro-work) 2.4g led driver 15w rf led controller 30-45vdc 350ma 2.4g wireless TDC led driver
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty(Year): 5-Year
Lighting Solutions Service: Lighting And Circuitry Design, Project Installation
Model Number: LKAD039D-A
Output Power: 20w-40W
Output Type: DUAL
Input Voltage: 100-277V
Output Frequency: 50/60Hz
Output Current: 700ma-1000ma
Output Power: 20-40W
Size: 135x45x25mm
Efficiency: 88%
Power Factor: >0.9
Function: 2.4G RF Remote Control Wireless-control
Type: 2.4g Wireless Cct Led Driver
Current Accuracy: ±3%
Feature: RF Frequency: 2.4GHz( Support Multiple Drivers Wireless-sync-work)
Application: Down Light,panel Light
Product Name: 2.4g Led Driver 15w Rf Led Controller 30-45vdc 350ma
Basic Infomation
Model Number: LKAD039D-A
Payment & Shipping Terms
Packaging Details: 2.4g led driver 15w rf led controller 30-45vdc 350ma 2.4g wireless cct led driver 1pc pack in 1 inner box, 40pcs in 1 carton
Supply Ability: 10000 Piece/Pieces per Month SMART LED DRIVER
Product Description
Product Description
2.4G control color temperature Adjusting LED drivers
This series 2.4G RF color temperature ajusting LED drivers adopt the press button RF wireless remote control, can adjust to change the lights color temperature according to the customer’s preference. 2.4G frequency make it more stable and more strong anti-jamming capability to use.
Product Paramenters
2.4g led driver 15w rf led controller 30-45vdc 350ma 2.4g wireless cct led driver
INPUT
Input Voltage
100-240VAC
Input frequency
50/60Hz
Power Factor
0.9
OUTPUT
DC Voltage
10-42VDC
Rated Current
700ma-1000mA
Rated Power
20w-40W
SETUP Rise Time
<0.5s
PROTECTION
Short circiut
Recovers automatically after fault condition is removed
Overload
Overload protected @110-130% above peak rating
Over Temperature
Shut down o/p voltage . re-power on to recover
IP Code
IP20
ENVIRONMENT
Working TEMP.
-30-+50℃ (refer to output load derating curve)
Storage TEMP.
-40-+80℃
Safety & EMC
Safety Standards
CE
EMC Test Stardands
ROHS EMC LVD
DIMENSION
135x45x25mm
Product Features
2.4g led driver 30w 700ma dimmable cct led controller
 -- The products default as dual constant current controller,need match remoter, create colorful static or dynamic effect.

-- Adopt 2.4GHz wireless technology

-- Can connect with external switches to achieve on/off and scene change function

-- The product can also be used as color temperature or dimmer controller, good compatibility.
Details Images
Certifications
Our products have TUV,CE,SAA,UL,FCC,CCC certifictes.
Installation Dimension
Installation Diagram
Recommend Products


Wireless Smart 2.4G remoter

2.4G remote is an accessoriy which is compatible with the 2.4G CCT dimming LED drivers. The function is to set the color temperature, brightness and change the mode for different scenes of LED lamps.
Company Profile
About Linkuan Power
Guangdong Linkuan Smat Tech Co., LTD. (hereinafter referred to as Linkuan Smart), formerly known as Dongguan Linkuan Semiconductor Lighting Co., Ltd., was founded in 2007. It is located in Dongguancity, a famous manufacturing city in China.The company plant area is about 4500 square meters, the registered capital is 10 million yuan, the staff is about 150 people, inclduing 30 management, engineering and technical persons.The company has 4 automatic production lines, 2 wave soldering machines, 5 sets of automatic constant temperature burning-test equipment, ultrasonic wave equipment and other efficient production equipment.
Factory Show
R&D Ability
Our Team
Delivery
Fast Delivery
Samples orders: 1-3 days Less than 50pcs should be sample order to us
OEM orders: 7-10 days Avaialbe for quantity within 1000pcs and 80W LED drivers
FAQ
1) Question: When was the LINKUAN Company established? Answer: Our company was established in 2005 with a registered capital of 30 million yuan. 2) Question: What is the main business of the LINKUAN? Answer: Since 2005, the company has been committed to the research and development of LED controllers / LED drivers / LED dimmers. It currently holds a leading position in the field of LED control and dimmer control. Our products are compatible with Lutron, Dynalite, Clipsal, LDS, Helvar, Osram, Philips, ABB, Schneider, Leviton, JUNG, Brocade, Simon, Lichtregler, etc. 3) Question: What are the main products of the LINKUAN? Answer: The collar products currently have Triac dimmable LED Driver / DALI dimmable led driver / 1-10v/0-10v led driver / led driver remote control 2.4g RF Wireless / Zigbee led driver / wifi led driver / tuya smart LED Driver / Bluetooth led driver / non dimmable LED Driver 1-400W, dmx512 controller, thyristor dimmer and other series of dimmers, dimming led power supplies, and load controllers, high voltage, low voltage, constant current, constant Pressure LED lighting fixtures can be equipped with corresponding controllers. Can be used with or with the following brand products: Lutron, Dynalite, Qisheng, LDS, Helvar, Osram, Philips, ABB, Schneider, Leviton, JUNG, Brocade, Simon, Lichtregler Wait. 4) Question: Is the product of the LINKUAN developed and designed by itself? What are the advantages? Answer: All of our products are self-developed and produced, and have their own intellectual property rights, and have won hundreds of national patents; our original digital dimming technology makes the dimming curve smooth and completely solves the stroboscopic and jitter problems; The products have been sold to more than 100 countries and regions around the world. 5) Question: What is the quality control system for the LINKUAN? Answer: We strictly control quality according to ISO9001:2008. Since 2008, our ISO9001:2008 certificate has been issued by SGS from Switzerland. 6) Question: What certifications and products do we have? Answer: We mainly issue UL FCC TUV CE, CB, SAA, C-Tick, PSE, ETL, CCC and other certificates issued by SGS from Switzerland. Many products from Australia, Japan, and China can be converted into the customer's own country certificate through our CB certificate. 7) Question: How long is our product warranty? Answer: The crown products are subject to strict quality control. The product warranty for low-voltage input is 5 years, and the product warranty for high-voltage input (110-220V) is 3 years. 8) Question: How do I purchase a product that leads? Answer: Our headquarters is located in Dongguan, and Zhongshan has an office. Please tell us the products you are interested in and the quantity ordered, we will send you a quote as soon as possible. Our standard products have an inventory of 80,000 units. It is our consistent advantage to respond quickly to the needs of our customers. If the product is not in stock, we will deliver it within two to four weeks. Mobile: +86 15899935775 Wechat: Nicole-HYL05 Skype: Nicolekoalaa 9) Question: What should I do if I have a problem after receiving the goods? Answer: Please describe the problem in detail. You may need to provide us with pictures of product connection and system settings. We will help you solve the problem as soon as possible. Incorrect connections and system settings are common problems. If our products have quality problems during the warranty period, they will be replaced free of charge
